Corrugated Carton Box Single Pass Digital Printing MachineGR1818
Description
Singlepass digital printing machine is a high-speed printing machine that has the ability to print an entire page in a single pass. It works by feeding the paper through the printer at a very high speed, while the printhead sprays ink onto the paper as it moves. This technology is often used for printing high-quality images or graphics on a corrugated board.
Honor GR1800 Series Single-Pass Type Main Features
1. Fast production. The max theoretical printing speed of ONE PASS high speed printer is 1.5m/second, this speed can compete with traditional printers.
2.Without film-plate making. no wasting time and cost. ONE PASS high speed printer does not require plate-making, uses advanced digital inkjet printing technology, easier and faster.
3.Envirnomental friendly. ONE PASS high speed printer uses four primary color inkjet printing technology, less washing, less waste water.
4.Reduce manpower. ONE PASS speed printing machine adopts computer drawing ,auto setup the photos to be printed saving time and labor with higher efficiency
Model | GR1818 |
Rip Software Rip | Maintop |
Picture Format | TIFF,JPG,PDF,PNG |
Print Head | EPSON Industrial ALL-MEMS Print Head |
No.s of Print Head | 18 |
Ink type and color | CMYK Water Based Ink |
Max. Printing Width | 533mm |
Media Thickness | 1-20mm |
Printing accuracy max. Printing Speed | 1.5m/s(300*600DPI) 0.8m/s(600*600DPI) 0.5m/s(900*600DPI) |
Min. Feeding Width | 400mm |
Max. Feeding Width | Standard 1800mm, customizable. |
Feeding Mode | Auto feeding |
Operating System | Windows 7 or Later Version |
Working Environment | 18~30℃,humidity:50%~70% |
Electric voltage | 380V±10% 50/60HZ |
Total Power | About 30KW AC220V50~60HZ |
Printer size(L*W*H) | 6800mm*5160mm*1980mm |
Printer weight | About 5500kg |
